Fast and precise layout ensures accuracy and increases productivity while eliminating rework.

Services We Provide

MEP Deck Layout

We will mark points on metal/wood decks or concrete for all your MEP needs. Each point will be labelled and numbered according to a QC plot we provide to you. You can install alongside us or afterwards.

Undergrounds

We will lay out your underground by marking stub-up locations, painting main/branch lines, and marking control lines. Before the concrete pour, we will verify your stub-up locations and provide a dimensioned overlay against your plan.

Architectural & Structural

We will layout or verify building corners, elevator cores, columns, walls, edge forms, embeds, grid lines, etc.

As-Builts & Scans

We provide dimensioned as-built drawings and data for the modeling process of mechanical rooms, boiler rooms, building remodels, etc.

Total Station Layout

Efficient and Timely Layout

Our versatile and experienced team provides a variety of field layout services to suit your needs. We frequently work with trades and general contractors throughout the Denver area and across Colorado to lay out architectural/structural members, sleeves, threaded anchor inserts, electrical equipment, and underground plumbing/piping. We can lay out points on wood and metal decking, in the dirt, on top of concrete slabs, and more.

Point Location / Data
Preparation

Coordinated Layout

We provide CAD services to locate your equipment and create dimensioned sleeve plots or layout plans. Each point on the plot will be numbered to aid in your QC process after our field layout.

If you have a CAD department locating your equipment, we just need an architectural CAD file and coordinates for your points.

BIM Modeling &
Coordination

Additional Services to Meet Your Needs

Our sister company 3DBIMworx provides BIM modeling and coordination services. We have a team of experts to provide a complete coordinated model including BOMs, spool sheets, and useful, usable reports showing the manufacturer’s parts and fabrication standards that your company uses. We draw dry and wet sides as well as electrical.
